lmage Sensor
|
Color CMD (Photosensitive Chip)
|
Lens Angle
|
90°
|
TV System
|
NTSC/PAL
|
Effective Pixels
|
510(H) x 492(V)
|
Horizontal Resolution
|
420 TVL
|
Sensing Area
|
4.08mm x 3.102mm
|
Shutter Speed
|
1/60-20 μs
|
Video Output
|
RCA Connector; 1.0 Vp-p, 752
|
Power Supply
|
12V |
Operating Temperature
|
-20℃ ~ +60℃ RH 95% Max |
Storage Temperature
|
-20℃ ~ +80℃ RH 95% Max |
Water Proof Rating
|
IP68 |
Minimum Illumination
|
0.1-0.5 Lux/F=1.2 (O Lux with IR on)
|
